Forage Harvester 4QZ-18
-
Expertly harvest and process crops with the Forage Harvester 4QZ-18.
With its precision and speed, this harvester is the perfect solution for any agricultural operation.
products profile
products details
The Forage Harvester 4QZ-18 is a reliable and efficient machine for harvesting crops.
Its precision cutting technology and adjustable settings ensure optimal harvest quality.
Increase your yield and efficiency with the Forage Harvester 4QZ-18.
Technical parameters
Model | 4QZ-18 | |
Dimensions in working state (L*W*H) (mm) | 8300*3560*5630 | |
Structural quality (kg) | 12060 | |
Supporting engine | Rated power (kW) | 264.8 |
Rated speed (r/min) | 2200 | |
Working width (mm) | 3300 | |
Wheel track | Guide wheel (mm) | 2240 |
Drive wheel (mm) | 2350 | |
Wheel base (mm) | 2680 | |
Guide wheel tire specification (self-propelled) (mm) | 400/70R24 | |
Driving wheel tire specification (self-propelled) (mm) | 23.1-26 | |
Straw shredding mechanism type | Roller | |
Operating speed range (km/h) | 2-6 | |
Cut length (mm) | 7, 10, 12, 14, 16, 18, 20, 22, 25 | |
Grain breaking type | Roller | |
Header cutter type | Rotary Disc Knife |
